| Features:
- 60/60Mbps, 40/40Mbps, 20/20Mbps speed selectable
- Remote Line Power over 2-wire or coaxial cables
- Easy installation and system setup procedure
- Auto MDIX for 10/100 BaseT Ethernet LAN Ports
- IEEE 802.3af PSE Compliant for Class 0-3.
- 4 Dip Switches for Master/Slave Configurations
- Low-Latency for Video/Voice/Data applications
Technical Specifications:
LAN Interface:
- Auto-Detection for 10/100 BaseT and Half/Full duplex
- Fully compatible with IEEE802.3/IEEE802.3u
- Automatic MDIX Function
- RJ-45 Connector x 1
Remote Line Power:
- Safety-Extra-Low-Voltage (SELV) Compliant
- Power Auto Restart with Under Voltage Lockout
(UVLO) Fault Detection
LED Indicators:
- POWER: Power is ON
- LINE: Loop Connection Status
- LAN: Data Activity of LAN Port
- M/S: Master/Slave
Physical Dimension:
- Desktop: 120 x 90 x 28 (mm)
Power: (for models with local power feeding)
- 12VDC 2.5A
Operating Environment:
- Humidity: 5% to 95% non-condensing
- Temperature: 0 ~ 50 degree C
Regulatory Compliance:
- FCC Rules Part 15
- CE |
